Python: Library Managment System -P3

June 18, 2020 4 comments


Learning : Python, DataBase, SQlite
Subject: Create Simple Library Managment System

In this Part we will work on Classification Managment. As we know each book can fall in one or more subject or say ‘Classification’ then we can search for a book by it’s class, example of this, we may have classifications like: cook, computer, Health, History; also a book can have more than one classifications such as one book we gave it cook and sweet .. and so-on.

To do this we add another table to the project to hold all the Classifications and manage them. Here is the code ..

# New Table to be added.

sql_class  = "CREATE TABLE if not exists classifi_list (class_id INTEGER PRIMARY KEY AUTOINCREMENT, class_name text )"
c.execute(sql_class)
db_conn.commit()

c.execute ("INSERT INTO classifi_list (class_id) VALUES(:class_id)",{"class_id":0})
db_conn.commit()

[NOTE: This code been added to the source file.]

Classification Managment: In Classification Managment we will have four Functions, and will write the codes to perform each function, also we will write the Menu Function to let the user select a function. Functions are:

1. Add New Classification.
2. Edit a Classification information.
3. Delete a Classification.
4. Show Classifications.

First: Here is the class_menu() Function, the user will have the prompt and asked to select an action or (9) to Exit.

# Classification Managment Fumction
def class_menu():

    while True :
        os.system('clear')
        print('\n   ====== LMS - Classification Managment ======')
        print('    1. Add New Classification.')
        print('    2. Edit a Classification information.')
        print('    3. Delete a Classification.')
        print('    4. Show Classifications')
        print('    9. Exit.')

        user_choice = input('\n   Select the Action you want from the Menu: ')

        if  user_choice == '1' :
            # Function to Add New Classification
            new_classification()

        elif user_choice == '2' :
            # Function to Edit a Classification information.
            edit_classification()

        elif user_choice == '3' :
            # Function to Delete a Classification.
            delete_classification()

        elif user_choice == '4' :
            # Function to Show a Classification.
            show_classification()

        elif user_choice == '9' :
            return



Now, let’s start with Add New Classification. Simply we will ask the user to write a classification to be added to the Database, then we will check if it is already available in our Database, If yes then we will till the user so, or (if not available) we will add it, and will give the user the chance to add another one. If the user enter (Q or q) then we exit (Quit) from the function and return to the previous Menu.

# Function to Add New Classification

def new_classification() :
    os.system('clear')
    print('\n   ====== Add New Classification ======')
    while True  :
        class_name = input('\n   Enter the Classification and Press Enter. [ To Exit Enter Q ].. >  ').capitalize()

        c.execute ("select * from classifi_list where class_name='{}'".format(class_name))
        result = c.fetchone()
        if class_name not in ['q','Q']:
            if (result != None) :
                print('\n   We already have [{}] in the Classification Database. '.format(class_name))
            else:
                c.execute ("INSERT INTO classifi_list (class_name) VALUES(:class_name)",{"class_name":class_name})
                db_conn.commit()
                print('\n      One Classification Added ... ')
        else:
            input('\n   To Exit ... Press any key ..')
            return
The Code
Code, Run-Time


Another Function to work on is Edit a Classification information In this one we will print-out all the Classifications we have and the user will select the one to Edit and will asked to Enter the ID number next to it. Then to Enter the New One and we will save it. Here is the code and the Out-put screen shot. To display all classifications on the screen we will use this code..

# Code to display the classifications on the screen

# First we list down all classifications.
    c.execute ("select * from classifi_list where class_id > 0  order by class_name")
    class_list = c.fetchall()
    for cla in range (0,(len(class_list)-1),4):
       try:
           print('{:<3}{:<20}'.format(class_list[cla][0],class_list[cla][1]),end="")
           print('{:<3}{:<20}'.format(class_list[cla+1][0],class_list[cla+1][1]),end="")
           print('{:<3}{:<20}'.format(class_list[cla+2][0],class_list[cla+2][1]),end="")
           print('{:<3}{:<20}'.format(class_list[cla+3][0],class_list[cla+3][1]))

       except:
           pass

[NOTE: We use the try: except to avoid any (index out of range) errors.]

Code
Code, Run-time



Next we will work on the Delete a Classification, Deleting may effect on some Books that uses that classification, so we need to till the user to confirm Deleting. Also we will use the same code to list down all the classifications and ask the user to enter the ID of the one to-be Deleted. Here is a part of the code to Delete a classification..

# Part of the code ..

del_class = input('\n\n   To Delete a Classification Enter it''s ID number [Q To Exit]  > ')

if del_class not in ['Q','q'] :
    c.execute ("select * from classifi_list where class_id = '{}' ".format(int(del_class)))
    c_to_del =  c.fetchone()[1]
    print('\n   Are you sure you want to Delete "{}" Classification? '.format(c_to_del))
    print('   This action may effect on books has this Classification.')
    user_approve = input('\n   If you are sure to Delete "{}" Press Y or N: > '.format(c_to_del))
    if user_approve in ['y','Y'] :
        c.execute ("delete from classifi_list where class_id = '{}' ".format(del_class))
        db_conn.commit()
        input('\n   One Classification has been Deleted... Press any Key > ')
    else:
        input('\n\n   You Select NOT to Delete the "{}" Classification, Press any key to go back.. '.format(c_to_del))

    if input('\n   Do you Want to Delete Another Classification? [Y,N] > ') in ['n','N'] :
         return
else:
    input('\n   You Select to Exit .. Press any Key > ')
    return

The Code Code Run-Time



Last Function to work in this post is Show Classifications the function we will list down all the Classifications on the screen. Very easy one, here it is

# Show Classification Function

def show_classification():
    os.system('clear')
    print('\n   ====== Show Classification ======')
    print('   The List of Classifications We Have, Sort in Alphbatic\n')
    c.execute ("select * from classifi_list where class_id > 0  order by class_name")
    class_list = c.fetchall()
    for cla in range (0,(len(class_list)-1),4):
       try:
           print('{:<3}{:<20}'.format(class_list[cla][0],class_list[cla][1]),end="")
           print('{:<3}{:<20}'.format(class_list[cla+1][0],class_list[cla+1][1]),end="")
           print('{:<3}{:<20}'.format(class_list[cla+2][0],class_list[cla+2][1]),end="")
           print('{:<3}{:<20}'.format(class_list[cla+3][0],class_list[cla+3][1]))

       except:
           # just in case error, pass and do nothing.
           pass
    input('\n\n         ... Press any Key ..')
Code
Code Run-time




What’s Coming In coming post, we will write the Functions to Manage the Authors.

[ NOTE ]
1. I am using Galaxy Tab and QPython3 App.
2. All the above codes are available in the Download Section/Page under the project name.
3. The application codes, Functions, Menus and other parts of the Application are subject of changes. In case of changes I will mention that.




:: Library Managment System ::

Part 1 Part 2 Part 3

To Download my Python code (.py) files Click-Here




Follow me on Twitter..




By: Ali Radwani




Python: Library Managment System -P2

June 16, 2020 5 comments


Learning : Python, DataBase, SQlite
Subject: Create Simple Library Managment System

The Data: In the Part-1 we Talk about the Entities that we will create and about the Data we will collect (Fields). So here we are writing them again and we will add classification for each book :
Books Entity: Book Name, Book Author, Date of publish, Edition Number, Book classification number.
Author Entity : Author name, Author Nationality, email, SMA (social media account).
From the Author information we can see that we need to define a new Entity to hold the SMA.
SMA Entity: SMA Name, SMA Link.
Class Entity: class Name.
Here is each entity and field :
book:

  • b_id integer PK
  • b_name text,
  • b_a_id integer,
  • b_isbn text,
  • b_dop text,
  • b_ed integer

author:

  • a_id integer PK
  • a_name text
  • a_email text

sma:

  • sma_id integer PK,
  • a_id integer,
  • sma_name text,
  • sma_link text

class:

  • class_id integer PK
  • class_name text
  • Now we will write the code to create the Database and set a connection

    # create the Database and set a connection

    import sqlite3, os

    # Create the data-base & name it as LMS.
    db_conn = sqlite3.connect ("LMS.db")

    # set the connection.
    c = db_conn.cursor()

    Now we will create the tables..

    # Function to create the tables

    def create_tables_() :
    # to create tables.
    sql_books = "CREATE TABLE if not exists books (b_id INTEGER PRIMARY KEY AUTOINCREMENT, b_name text, b_a_id integer,b_isbn text, b_dop text, b_ed integer)"

    sql_author = "CREATE TABLE if not exists author (a_id INTEGER PRIMARY KEY AUTOINCREMENT ,a_ name text, a_email text )"

    sql_class = "CREATE TABLE if not exists classifi_list (class_id INTEGER PRIMARY KEY AUTOINCREMENT, class_name text )"



    sql_b_class = "CREATE TABLE if not exists b_class (b_class_id INTEGER PRIMARY KEY AUTOINCREMENT, b_id integer, class_id integer )"

    sql_sma = "CREATE TABLE if not exists sma (sma_id INTEGER PRIMARY KEY AUTOINCREMENT, a_id integer,sma_name text, sma_link text)"


    c.execute(sql_books)
    db_conn.commit()

    c.execute(sql_author)
    db_conn.commit()

    c.execute(sql_class)
    db_conn.commit()


    c.execute(sql_b_class)
    db_conn.commit()

    c.execute(sql_sma)
    db_conn.commit()

    input('\n .. LMS Tables created.. Press any key .. ')

    After creating the tables, and to make sure that AUTOINCREMENT of Primary key will run we need to have a number in each PK field, to do that we will add a 0 (Zero) record to each table. Here is the code to do it ..

    #Function to Insert the Zero Record

    #Function to Insert the Zero Record.
    def insert_record_0():

    c.execute ("INSERT INTO books (b_id) VALUES(:b_id)",{"b_id":0})
    c.execute ("INSERT INTO authors (a_id) VALUES(:a_id)",{"a_id":0})
    c.execute ("INSERT INTO classifi_list (class_id) VALUES(:class_id)",{"class_id":0})

    c.execute ("INSERT INTO b_class (class_id) VALUES(:class_id)",{"class_id":0})
    c.execute ("INSERT INTO sma (sma_id) VALUES(:sma_id)",{"sma_id":0})

    db_conn.commit()

    input('\n ...Dummy records been Inserted .... Press any key .. ')

    The above functions create_tables_() and insert_record_0() will be run only one time to create the tables, and insert record number ZERO. During the programming and coding we may need to delete the DataBase and re-created again, in that case we run the both functions again.

    Create the Menus
    As we side, each Entities will have three Main Functions [Add, Edit, delete ad search]. Let’s start with Main Menu.

    Main Menu Code
    Main Menu Run-Time
    Book Menu, Code
    Book Menu, Run-Time
    Author Menu, Code
    Author Menu, Run-Time
    Classification Menu, Code
    Classification Menu, Run-Time
    Search Menu, Code Search Menu, Run-Time

    What’s Coming In coming post, we will write the Functions to Manage the Authors and Classifications.

    [ NOTE ]
    1. I am using Galaxy Tab and QPython3 App.
    2. All the above codes are available in the download section/page under the project name.
    3. During the progress of the project, we may need to Add, Edit or delete any Tables, Fields, Menus or Functions that we had already finished.

    :: Library Managment System ::


    Part 1 Part 2

    To Download my Python code (.py) files Click-Here


Follow me on Twitter..


By: Ali Radwani

Python: Library Managment System -P1

June 14, 2020 5 comments


Learning : Python, DataBase, SQlite
Subject: Create Simple Library Managment System

Details: The project is to Plann, design and builed a simple Library Managment System LMS (For Books), the main Functions in the system are: (In this Version 1)

  • Add New Book.
  • Edit an exsit Book.
  • Delete a Book.
  • Search.

Planning: In this step we need to sit with the Business owner to identify the problem and plann the project. Since we will work as Fullstack (mean we will do every thing) and this is a training session project, we will be the Business owner of the project and will talk about the problem.

The Problem: In a very simple way, we have some Books and we want a System to store the books in a way that we can retrieve it’s basic information such as Title, Author, Subject and other information about it. Also we need to do some basic search to get statistics about our Library.

Data Gathering: First we need to define the Data we want to stoe, as we are talking about a simple Books Library System we can predict this very easily by looking to a book that we have and write-dowan the keys part of the book we want to store.
In this project we have three main Entities : Books, Authors, Borrowers. In this version (V.01) of the project we will NOT cover the borrowing functionality. So we will store the following data:

Books Entity: Book Name, Book Author, Date of publish, Edition Number, Book classification number.

Author Entity : Author name, Author Nationality, email, SMA (social media account).
From the Author information we can see that we need to define a new Entity to hold the SMA.
SMA Entity: SMA Name, SMA Link.

To Manage our System we will write Four main functions for each entity:
ADD, Edit, Delete and search.

Part 2: In Part-2 we will create the tables (The Entities), Insert the Zero-Row and create the Main Menu for each Entities.


:: Library Managment System ::

Part 1 Part 2 Part 3 Part 4



To Download my Python code (.py) files Click-Here




Follow me on Twitter..




By: Ali Radwani




Python: Drawing Math Equations



Learning : Python and Math
Subject: Python Project to Draw a Math Equations

In the past week or so I saw a tweet from @matthen2 it was about drawing half circles on 99 points, the 99 points was distributed on a hidden circle, each line (or half circle) connecting x (a point on the circle) and it’s double, so point num 2 is connected to P num 4; (P3 to P6, P4 to P8, …) and so-on

This inspired me to write a Python app (code) to perform same action. Then I just upgrade the idea to draw any mathematical Equation. (Lets say simple mathematical Equations)

In our project, the user will enter the number of points and the starting circle radius, also I fond that we can do more by reducing the circle radius after each point, so i add this to the project.

Coding: We will write a function to collect the points in a list as [x,y], and returns the list. Then we pass each two points of (x1,y1) and (x2,y2) to another Function to draw a line between those points. In this version we will write the Equations as hard-code in our project.

So First Function will be the get_points() here the systems will ask the user to Enter some variables. We will collect the number of points P, the raidus of the circle circumference that points will be distributed On it’s, also we will ask the user if circle radius is fixed or decreased by a given factor.
Using mathematics we know that a circle has 360degree, so if we divide 360 over P we will have (if we can call it) the arc_angle. .. Here is the code for the function …

# Function to collect the x,y points

def get_points() :
  p = int(input('  Enter number of Points:  ')) # number of points.

  arc_angle = 360 / p
  circle_r = int(input('  Enter the Cricle Radius: ') )
  fix_r = int(input('  Enter a number to reduce the Radius:'))

  #To return the x,y list of the points that we want to connect.
  p_list = []
  t.goto(0,0)
  t.setheading(-90)

  for p in range (0,p+1) :

    t.goto(0,0)
    t.forward(circle_r)
    nx = t.xcor()
    ny = t.ycor()

     # If the user want to reduce the radius.
    circle_r = circle_r - fix_r
    p_list.append([nx,ny])
    t.right(-arc_angle)

  return p_list



By now, we have a list of points [x,y], and we will passing two points to another function def draw_line(x1, y1, x2, y2): to draw a line between the points. Very simple and easy Function …

# Function to draw a line

def draw_line(x1, y1, x2, y2):

  t.goto(x1,y1)
  t.pendown()
  t.goto(x2,y2)
  t.penup()


Now the tricky part, How to select the points?. To do this we assume we have an Equation (e1) and if we got any errors like (division by zero, or out of index) we will apply another Equation (e2), e1 and e2 will be hard-coded and each time we need to change it and run the application again to see the result. And to draw a line between the points based on e1 and e2 we will run a for loop …. Here is the code ..

# drawing the equations



for d in range(len(p_list)-1) :

  e1 = d * 2
  e2 =  abs( len(p_list) - (d*2))

  try:
    draw_line(p_list[d][0], p_list[d][1],p_list[e1][0], p_list[e1][1])
  except:
    if e1 > len(p_list) :
      draw_line(p_list[d][0], p_list[d][1],p_list[e2][0], p_list[e2][1])


Here is some output




This is the end of this project, Do we need any upgrading in any part of it?



To Download my Python code (.py) files Click-Here




Follow me on Twitter..




By: Ali Radwani




Python : Triangle Parameters



Learning : Python to Draw a Triangle
Subject: To get the Parameters of a Triangle

A week ago I start helping a friend in a mathematics geometric to draw a Triangle from Two points that represent the The Hypotenuse of a Triangle, then I deside to write a python project to Draw a triangle based on two given points (x1,y1) and (x2,y2) and to print it’s parameter (other sides and angles). We will use the Trinket.io as a Python interrapter and will draw with turtle library.

Project Details: The system will ask the user to Enter the coordinates of Two points To draw a Right Angle Triangle. In our Triangle, we will call the (x1,y1) as Point A, and (x2,y2) as Point C. From our starting poins we can calculate the distance between point A and point (B), also the length of Hypotenuse and the angels in the Triangle.

So, What we have:

tri_opposite = abs( y2 – y1 )

tri_adjacent = abs( x2 – x1 )

From a mathimatics triangle formula we know that:

Opposite^2 + Adjacent^2 = Hypotenuse^2

where: x^2 = square(x)

So:

tri_hypo = tri_opposite**2 + tri_adjacent**2

tri_hypo = math.sqrt(tri_hypo)

tri_hypo is the distance between point A and Point C (the opposite
side of the right angle)

Now the Angels:
As we know that in a triangle the summation on all inside angles is 180deg, and in a Right Triangle we will have a one fixed 90 degree angle (ABC), so the first thing we will work on calculating the Opposite angle (BAC).

From a Triangle math:

tri_opposite = abs( y2 – y1)

tri_adjacent = abs(x2 -x1)

the_deg (BAC) = inverse tan for (tri_opposite / tri_adjacent)

# get the inverse of Tan

the_ang = math.degrees(math.atan(the_deg))

Now, lets do some coding ..

First thing we will import two libraries turtle and math, also we will do some setting for our turtle. … Here is the code ..

# Turtle setting


import turtle, math
# turtle_setting
t = turtle.Turtle()
t.penup()
t.shape("non")
#t.speed(9)
t.speed('fastes')
#t.visible = False

t.hideturtle()



Then we will write a code to draw a ‘Gray’ coordinates cross lines for our project. Here is the code for it ..



def the_cross() :
     # To draw the cross represents the coordinate.
    t.penup()
    t.pencolor('gray')
    t.goto(-200,0)
    t.setheading(0)
    t.pendown()
    t.forward(400)
    t.penup()
    t.goto(0,200)
    t.setheading(90)
    t.pendown()
    t.forward(-400)
    t.penup()
    t.goto(2,0)
    t.pendown()
    t.circle(2)
    t.penup()
    t.goto(0,0)
    t.setheading(0)

# calling the function
the_cross()


Now we will write the main function code, First we will ask the user to enter the x,y for two points, then we will do our calculations to get other Triangle parameters and angles, finally we will draw the Triangle. .. Here is the code..



def draw_triangle(x1, y1, x2, y2) :

# draw the Triangle.
    style = ('Courier', 20)   # font style.
    t.penup()
    t.goto(x1,y1)
    t.setheading(0)
    t.pendown()
    t.circle(1)  # To draw small circle on point A.
    t.write('A',font = style)  # To write A next to the point.
    t.forward((x2-x1))
    x3 = t.xcor() # here is the x for point B
    y3 = t.ycor() # here is the y for point B

    t.right(-90)
    t.forward((y2-y1))
    t.write('C',font = style)  # To write C next to the point.
    t.goto(x2,y2)
    t.setheading(0)
    t.pendown()
    t.circle(1)  # To draw small circle on point C.
    t.penup()
    t.goto(x3,y3)
    t.pendown()
    t.circle(1)  # To draw small circle on point B.
    t.penup()
    t.setpos(x3-15,y3-15)
    t.write('B',font = style)  # To write B next to the point.


    # To calculate the angle of BAC using Triangle Math Equations.
    tri_opposite = abs( y2 - y1)
    tri_adjacent = abs(x2 -x1)
    the_deg = tri_opposite /  tri_adjacent

    # get the inverse ot Tan using Triangle Math Equations.
    the_ang = math.degrees(math.atan(the_deg)) #atan(x) is the inverse of math Tan function.

    t.goto(x1,y1)

    # To correct the rotation angle based on it's coordinates.
    if (x1 > x3) and (y2 > y1) :
      rotation = the_ang - 180

    elif (x1  y1):
      rotation =  360 - the_ang

    elif (x1 > x3) and  (y2 < y1) :
      rotation =  180 - the_ang

    elif (x1 < x3) and  (y2 < y1) :
      rotation =   the_ang - 360

    #t.right(rotation)
    #t.pendown()
# From using Triangle Math Equations, we know that Hypotenuse^2 = Opposite^2 + adjacent^2.

    tri_hypo = tri_opposite**2 + tri_adjacent**2
    tri_hypo = math.sqrt(tri_hypo)
    t.right(rotation)
    t.pendown()
    t.forward(tri_hypo)
    t.penup()

    print('\n  The Triangle Information:')
    print('  Point A= ({},{})'.format(x1,y1))
    print('  Point B= ({},{})'.format(x3,y3))
    print('  Point C= ({},{})'.format(x2,y2))
    print('  Adjacent',tri_adjacent)
    print('  Opposite',tri_opposite)
    print('  Hypotenuse',tri_hypo)
    print('  Angle: ABC = 90')
    print('  Angle: BAC = ',the_ang)
    print('  Angle: ACB = ',180 - the_ang - 90)


Finally, we need to call the function and pass the two point to it, to do this first we will ask the user to Enter the Two Points and we will make sure that the points are not the same.. Here is the code ..

# calling the draw_triangle function ..

print('\n   To draw the Triangle you need to Enter Two Points as X,Y for each one.')
x1 = int(input('   Enter x for First point: '))
y1 = int(input('   Enter y for First point: '))
x2 = int(input('   Enter x for Second point: '))
y2 = int(input('   Enter y for Second point: '))

if (x2==x1) or (y2==y1) :
   print('  Your Points are not valid, (x1,x2) or (y1,y2) can't be equal ')
else :
   draw_triangle(x1, y1, x2, y2)




To Download my Python code (.py) files Click-Here




Follow me on Twitter..




By: Ali Radwani




Python: Covid19 Function Upgrade 1

April 16, 2020 Leave a comment


Learning : Using Beautifulsoup in Python
Subject: Python & Covid19 Function ‘Data By Country Upgrade

In last post (Python and Covid19) we use the Beautifulsoup and other libraries to grab COVID19 data from the internet and display it on the screen using our Main-Menu and some functions, and we said that some of those functions need some enhancement. In this post we will do some upgrade to one of the functions ‘def covid19_in_country()‘ and we will add the version number to it’s name as (def covid19_in_country_v02()).

In the previous Version of the function, we list down all the countries name with there indexes and ask the user to enter the index number of a country to get it’s COVID19 Data. However in this version we will give the user an option to select wither to:
1. Select the Country Name from a list.
2. Write the Country Name.

So if the user go-for option [1] then this will be as version 1, and if the user select option [2] then we will provide the opportunity to Enter Full or Part of a country Name and we will search for similar input (in the country list) and list them. Here is a screen shot of the RUN-Time ..


First we will write a code to create a list of Countries and there Indexes, this new function will called ‘def country_list()’ and it will return a list variable named ‘c_name_list’, here is the code for it.

# Function to create Country List

def country_list() :
    c_name_list=[]
    total_rows = soup.find_all('th',class_='covid-total-row')
    Total_Countries = int((total_rows)[0].b.text)
    for x in range (2,Total_Countries) :
            try:
                c_name_list.append([x,trs[x].find('a',title=re.compile('2020 coronavirus pandemic in *')).text])

            except:
                pass # If any errors, just pass.
    return c_name_list


Now we will split a part that (displaying the Country Data) from the main function ‘covid19_in_country()’ to be as an objet so we can call it any time with passing the country index to it. Here is the code..

# Code to display COVID19 data on the screen.

def show_counry_data(user_c_index) :
    # This will print the country name.
    print('\n\n     ',trs[int(user_c_index)].find('a',title=re.compile('2020 coronavirus pandemic in *')).text)
    # This will print the country information.
    tds = trs[int(user_c_index)].find_all('td')
    print('        Country Rank is: ',int(user_c_index)-1)
    print('        Cases:',tds[0].text.strip())
    print('        Deths:',tds[1].text.strip())
    print('        Recoveries:',tds[2].text.strip())




No we will re-write the main function of covid19_in_country() and we will add version number to it so it will be “covid19_in_country_v02()“. Here is the code ..

# covid19_in_country_v02()


def covid19_in_country_v02() :
    """
    Version: 02.13.4.2020
    """
    os.system('clear')
    print('\n    Covid19 Country Data.')
    print('\n    ',last_update,'\n')

    while True:

        print('\n   Do you want to:' )
        print('   1. Select the Country name from a list.' )
        print('   2. Write the Country Name.')
        country_as = input('\n   Select from the Menu [1,2]: ')
        if country_as in ['1','2'] :
            break
        else:
            print('\n    You Must Select [1 or 2] ... Try Again .. ')

    c_name_list = country_list()
    if country_as =='1' :
    # First we will print-out the list of counries name.
        for cou in range (0,(len(c_name_list)),4) :
            try:
                print ('    ',c_name_list[cou],c_name_list[cou+1],c_name_list[cou+2],c_name_list[cou+3])
            except:
                pass # if any error just continue.

        while True :
            user_c_index = (input('\n\n    Enter the Index number of the Country to see it''s Data. [e to Exit] '))
            try :
                show_counry_data(user_c_index)
            except :
                if ((str(user_c_index)) in ['e','E']) :
                    return
                else :
                    print('\n    You must Enter a Number or ''e''/''E'' to exit')


    if country_as =='2' :

        print('\n   You Select the option to Enter a Country Name.')
        search_country = input('   Enter the Country Name (or Part of it): ')
        print('  You enter: ',search_country)
        c_indexes=[]
        for x in range (0,(len(c_name_list))) :
            try :
                if (search_country.casefold()) in (c_name_list[x][1]).casefold() :
                    c_indexes.append([c_name_list[x][0],c_name_list[x][1]])
            except:
                 pass
        if (len(c_indexes)==0) :
            print('\n   We can''t find your search, this may due to:')
            print('   1. Spelling error.')
            print('   2. Country Name drops for some technical error.')
            input('\n    ... Press any key ...'')
            return

        else :
            print('\n   We fond {} matches with your search, Enter the Index Number for the\n   one you are looking for: '.format(len(c_indexes)))
            print('\n\n ',c_indexes)

            show_counry_data(int(input('\n   Enter the Counrty Index Now: ')))

    input('   ... Press Any Key ...')



This application and the code was written as a matter of training and learning. The owner/creator is not responsible for any missing or wrong data may exist in the file and/or the Data. (the code and/or the data-sets).



Note That: The file will only contain the changes in the function, NOT the Full COVID19 APP.

To Download my Python code (.py) files Click-Here




Follow me on Twitter..




By: Ali Radwani




Python and Covid-19

April 13, 2020 1 comment


Learning : Using Beautifulsoup in Python
Subject: Grab Data from a Website Using Python

In this article we will use Python codes to fetche some data from a website, the Data we are looking for is about Covid-19, to do this we can use an API but here I am using web crawler with Beautifulsoup. So let’s start.

Introduction: First we need a Data Source web-Page, if we search the web we will find a lot of pages there I select this one (en.m.wikipedia.org/wiki/2019%E2%80%9320_coronavirus_pandemic_by_country_and_territory) Source:wikipedia.org, you need a basic knowledge about HTML to understand the stag’s. After reading the web-page source code we can found the following:
1. The HTML code structure contain 9 Tables.
2. The Data about Covid-19 is in Table No. 2.
3. The Table consist of several ‘tr’ Tag. In HTML ‘tr’ tag is Row.
4. Each ‘tr’ consist of several ‘td’ Tag. In HTML ‘td’ tag is Colunm.
5. Each ‘td’ may contain other tags or information, and some of those information are what we are looking for. We will talk about this later in bellow.

Now we will talk about our Python Application. We will write a Python Application that will display a Menu on the screen and ask the user to select from the Menu, and based on the user selection we will run a function to perform something, in our case we will have a Menu with four choice of selection as:
1. The Totals in the world.
2. The covid-19 by countries.
3. Covid-19 Table.
9. Exit.

To start writing our code, First we need to import some library we here is the code..

# To import needed Libraries

import requests, os, re
from bs4 import BeautifulSoup

The Menu: As we mentioned we will have a Main-Menu to help the users in there selections. Here is the code:

# COVID-19 APP MAIN MENU

def covid19_menu() :

    while True :
        # This will Clear the terminal
        os.system('clear')
        print ('\n    =====[ COVID-19 APP MAIN MENU ]=====')
        print('    1. The Total in the World.')
        print('    2. The covid-19 by Countries')
        print('    3. Covid-19 Table. ')
        print('    9. Exit')

        user_input = input('\n    Enter Your choice: ')

        if user_input in ['1','2','3','9'] :
            if user_input =='1' :
                covid19_world_total()

            if user_input =='2' :
                covid19_in_country()

            if user_input =='3' :
                covid19_table()

            if user_input =='9' :
                return

        else :
            print (' You Must select from the above Menu.')
            input('\n      ... Press any key ...')



Now we will work on First function, before that we will write this two lines of code to set my_url (the webpage we want to read), and calling the BeautifulSoup for it, so all the webpage source will be as text in variable soup:

# To load the page in a variable soup
my_url ='https://en.m.wikipedia.org/wiki/2019%E2%80%9320_coronavirus_pandemic_by_country_and_territory'
source = requests.get(my_url, headers = headers).text
soup = BeautifulSoup(source, 'lxml')


Now our first function will get the last update of the data (Date and Time), after searching the web-site code, I found that the page contain 19 ‘P’ tag’s and the last update statement is in fifth Paragraph, but in case that the page may updated with more data or the page structure changed, we will write a code to search for it. Here is the function to get the Data last Update statement.

# Function to get Last update statement

def get_last_update():
    update_date_time = soup.find_all('p')
    # I found the date in P = 5, but i will search other the 19 P's
    for thep in range (0,19) :
        if 'UTC on' in update_date_time[thep].text :
            last_update='The Data Updated on ' + update_date_time[thep].text[6:32]
            return last_update
        else:
            thep = thep + 1


Now, our function will get the four set of information for Grand Totals in the world as Total Countries has COVID-19, Total Cases of COVID-19, Total Deaths by COVID-19 and Total Recoveries from COVID-19. Here is the function

# Function to get the covid19 World Totals

def covid19_world_total():
    os.system('clear')
    print('\n    ',last_update,'\n')
    # This section will fetch th Total Rows.
    total_rows = soup.find_all('th',class_='covid-total-row')
    # We know that total_rows has 4 lines, so we will access them as individual.
    print('\n   ::: TOTAL NUMBERS :::')
    print('   Total Countries has COVID-19:   ',(total_rows)[0].b.text)
    print('   Total Cases of COVID-19:        ',(total_rows)[1].b.text)
    print('   Total Deaths by COVID-19:       ',(total_rows)[2].b.text)
    print('   Total Recoveries from COVID-19: ',(total_rows)[3].b.text)
    input('\n    ... Press any Key ...')
RUN-Time:


Second function we will work on is covid19_table, in this function we will print-out a table of covid19 contains countries Name, cases, Deaths and Recoveries sorted by Number of cases. In this version of application we will display only 10 records.


Enhancement: In a Coming version the user will select the number of records also the sorting type.

# Function to print-out the Covid19 cases.
def covid19_table(top =10):
    """
    This Function will print-out the countries table sorted by Number of cases.
    If the user did not select number of countries then defult will be first 10.
    """
    os.system('clear')
    print('\n   The List of Countries has Covid-19, Sorted by Total Cases..')
    print('   ',last_update,'\n')

    r_spc = 30
    tab_offset = (r_spc-1)
    # To print the Table Header.
    print('-'*r_spc,'+','-'*20, '+','-'*21,'+','-'*20)
    print(' '*8,'{0:<20}  |       {1:<15}|      {2:<17}|     {3:<20}'.format('Countries','Cases','Deths','Recoveries'))
    print('-'*r_spc,'+','-'*20, '+','-'*21,'+','-'*20)

    droped_data =[]
    c = 2
    while c <= top :
        try:
            # This will print the country name.
            contry_name = trs[c].find('a',title=re.compile('2020 coronavirus pandemic in *'))
            tds = trs[c].find_all('td')
            c_offset = len(contry_name.text.strip())
            print('   ',c-1,'-',contry_name.text.strip(),' '*(tab_offset - c_offset),(tds[0].text).strip(),' '*(30 -(20 + len((tds[0].text).strip())) +10) ,(tds[1].text).strip(),' '*(30 -(20 + len((tds[1].text).strip())) +12),(tds[2].text).strip())

        except :
            droped_data.append([c])
        c = c + 1
    print('\n\n    We have {} Droped Country(ies) due to some error'.format(len(droped_data)))
    input('\n   .. Press  Any Key ... ')


RUN-TIME


In the last Function, we will let the user to select the Country name then we will display the Covid19 information regarding his selection. So to perform this action, First we will create a list of all Countries Name, and display the list on the screen asking the user to select (Enter) the index number of any Country, then we search for that country name and grab it’s Covid19 Data. Here is the code..

# Function to grab Covid19 Data by country.

def covid19_in_country() :

    os.system('clear')
    print('\n    Covid19 Country Data.')
    print('\n    ',last_update,'\n')

    # First we will build a list of counries name.
    c_name_list=[]
    total_rows = soup.find_all('th',class_='covid-total-row')
    Total_Countries = int((total_rows)[0].b.text)
    drops_c = 0
    for x in range (2,Total_Countries) :
        try:
            c_name_list.append([x,trs[x].find('a',title=re.compile('2020 coronavirus pandemic in *')).text])

        except:
            drops_c +=1

    print('    We miss {} Countries due to some errors.'.format(drops_c))
    print('\n    Enter the Country Number to show it''s Data.')
    for cou in range (0,(len(c_name_list)),4) :
        try:
            print ('    ',c_name_list[cou],c_name_list[cou+1],c_name_list[cou+2],c_name_list[cou+3])
        except:
            pass # If there is an error just pass.

    while True :
        user_c_index = (input('\n\n    Enter the Index number of the Country to see it''s Data. [e to Exit] '))
        try:
            if (isinstance(int(user_c_index), int)) :
                # This will print the country name.
                print('\n\n     ',trs[int(user_c_index)].find('a',title=re.compile('2020 coronavirus pandemic in *')).text)

                # This will print the country information.
                tds = trs[int(user_c_index)].find_all('td')
                print('        Country Rank is: ',int(user_c_index)-1)
                print('        Cases:',tds[0].text.strip())
                print('        Deths:',tds[1].text.strip())
                print('        Recoveries:',tds[2].text.strip())
        except :
            if ((str(user_c_index)) in ['e','E']) :
                return
            else :
                print('\n    You must Enter a Number or ''e''/''E'' to exit')

    input('   ... Press Any Key ...')



This application and the code was written as a matter of training and learning. The owner/creator is not responsible for any missing or wrong data may exist in the file and/or the Data. (the code and/or the data-sets).



To Download my Python code (.py) files Click-Here




Follow me on Twitter..




By: Ali Radwani




Excel : Form to Save Data P-1

March 31, 2020 Leave a comment


Learning : VBA Codes to Save Data
Subject: Create Form to collect Data

In a very fast and as simple as we can, we will design and write VBA codes to transform three fields of Data from an Excel sheet “Form” to another sheet “Data”.

To keep thing as simple as we can, we will not use any Validations on user inputs in this example.


First, we will re-name a sheet to “Form” and another one to “Data”. In sheet [Form] we will create a simple Form to collect Names, Company Name and Emails of our customers, also we add a button and call it Save. As in Image-1

Image-1


For companies Name, We will create a list then we will link it to Cell”D9″ so we can select a “Company Name” from a drop-down list. So to do this First in the Data sheet I will write a list of companies Name as (Comp Name 1,Comp Name 2,Comp Name 3, …. to Comp Name 10). I start my list from Cell “H8” [As in Image-2] you may start from any Cell you want.

Image-2


Now to link a Dropdown list of our companies Name to Cell “D9″ Do this:
1. Goto Cell”D9”.
2. From the menu we will select “Data” then “Data Validation” and select Data Validation. [Image-3]

Image-3


3. In the Allow [Select “List”], then in the Source we select the range of Companies we write [Range Cells H8:H17] or just write this: =$H$8:$H$17. Then click OK. See Image-4

Image-4

Now if we try to click on Cell “D9” we will have a list as in Image-5.

Image-5

In the “Data” Sheet we will just create the Table Header as in Image-6, and will go-back to “Form” Sheet.

Image-6


Now we will write the VBA codes and link it to to a “Save” Button we create. To open the Visual-Basic window we select “Developer” From the Top menu, then Press Visual Basic.

Then we write this code and link it to the Save Button. ..

 # VBA Macro code to Save Data to Data sheet

Sub Save_data()
'
' Save_data Macro
' Macro recorded 2020-03-29 by HP
'

'
    ' Set Variables
    Name = Range("D7").Value
    comp_name = Range("D9").Value
    Email = Range("D11").Value


    ' Goto data sheet
    Sheets("Data").Select
    ' This line will get the Next empty Row in the Data sheet.
    emp_row = Range("A" & Rows.Count).End(xlUp).Offset(1).Row
    Range("A" & emp_row).Value = Name
    Range("B" & emp_row).Value = comp_name
    Range("C" & emp_row).Value = Email

    'Go to Form Sheet.
    Sheets("Form").Select

    ' Clear data cells.
    Range("D7").Value = ""
    Range("D9").Value = ""
    Range("D11").Value = ""

    Range("D7").Select

End Sub



Now if we enter some data [as we said: No Validation on the data] and press the Save button, the data will be coped to next empty row in the Data Sheet.



Enhancement: In some cases as in our coming project, it’s better to create a sheet and call it “Setting”, then we can have our Lists (such as Company-Name), Colors, Filters all to be in the Setting sheet. [We will see this in the Next Project.]



Follow me on Twitter..




By: Ali Radwani




Excel, VBA Codes and Formulas-4

March 26, 2020 Leave a comment

Learn To : In Excel – Highlight the Row when clicked.


Assume we have a table, and all we want to do is that if the user click anywhere in the table that ROW will change it’s color.



Steps
1. From the Top menu, Go to “Developer”, then Press Visual Basic.



2. from the select the sheet name containing the table. ( We have it in Sheet 2 )
3. Then we select “SelectionChange” action from the




4. Write this code:
If Not Intersect(ActiveCell, Range(“C8:E9999”)) Is Nothing Then
Range(“A1”).Value = Target.Row

End If

5. You need to know your Table Range, in my example, the range is (“C8:E9999”). I add the “9999” so i will be sure the even if we add more data to out Table the code will handle it.

6. Now we need to add a rule in the “Manage Roles” in “Conditional Formatting” from the Excel Menu. Here is how to Open it.


7. Select the “” then add new Rule, Follow the Image showing the steps to do that. Once we finish it should work fine.



Now, when the user click any cell in the Table the Row will change it’s color (Format) as we set it.

🙂 Have Fun ..



Follow me on Twitter..




By: Ali Radwani




Excel, VBA Codes and Formulas-3

March 22, 2020 Leave a comment

Learn To : In Excel – SUMIF and SUMIFS [ Part-2 SUMIFs ]


In SUMIFS we are talking about more than one conditions to apply on the same range or other range before we calculate the SUM of the target range.

Case Assumption: As in Part-1, Assume we have a table, with 5 columns (as in image-1) columns titles are [Date, Item, Quantity, Price and Total] containing our Expendituer and we have another table call it Summaries, we want some totals to be in this table. We can see the main table [Expendituer] and the Summary table as in part-1 but here we will add a year column to the Item-Quantity box, so we want to have the Quantity of an Item in given year. Image-2.

Image-1

Image-2

So if we write 2018 in Cell I27 we Must get the Quantity of School Bags we bought in 2018. To do this we will write this formula:

SUMIFS ()

=SUMIFS(E22:E30, D22:D30,J28,C22:C30,”*”&I28)

So in Cell K28 we will write =SUMIFS(E22:E30, D22:D30,J28,C22:C30,”*”&I28)

then we can copy the formula to other cells.


Now we have the formula in all the cells we want, we may need to do a little changes to cells number or columns that may been changed during the copy. And here is a screen shot of what we must have.


🙂 Have Fun ..



Follow me on Twitter..




By: Ali Radwani
