## Another sketch challenge: The House

This week sketch challenge @1hour1sketch on Twitter is to Draw a House so here is my sketch using pencil then black Pen, it takes around 25min. More Sketches on my Sketch page ..

Here is my sketch.. ## Another sketch challenge: Eagle Face

This week sketch challenge @1hour1sketch on Twitter is to Draw an Eagle Face, so here is my sketch using pencil then black Pen, it takes around 15min. More Sketches on my Sketch page ..

Here is my sketch.. ## Python Project: Disarium Numbers in Range

Learning : python code
Subject: Finding the Disarium number
in a range

[NOTE: To keep the code as simple as we can, We WILL NOT ADD any user input Varevecations. Assuming that our user will Enter the right inputs.]

Definition We call a Number as A Disarium Number if the Sum of it’s Ddigits Powered with their Respective Position is Equal to the Original Number.
So 89 is a Disarium Number, because 8^1 + 9^2 = 8 + 81 = (89 the original number)
and 135 is also a Disarium Number, because 1^1 = 1, 3^2 = 9, 5^3 = 125 and the Total is [1+3+125 = 135 the original number]
we have a previous post to check if a given number is a Disarium Number or not … Read The Post Here .. In this post we will write the Function to print-out all the Disarium Numbers in a given range.

So our application will ask the user to enter two Numbers as a range From and To, then the disarium_n_range(num1,num2) taking two argument will work through a For loop to check each number in the range and if it is a Disarium Number we will store it in a list (disarium_n =[]) .. Let’s start by the asking the user to Input the range numbers..

``` # Code to collect the Numbers from the User

print('\n\n   This Project will Print-Out all the Disarium Numbers in a given range.')
num1 = input('\n   Enter the From Number. > ')
num2 = input('\n   Enter the To Number.   > ')
```

And now let’s see the main Function of the application ..

End of the post .. Follow me on Twitter..

## Python: Sorting Algorithm (1.Quick Sort)

Learning : SQL, Python, sqlite, DataBase
Subject: Testing the SQL Join commands using Python.

Sorting Algorithm is a way to sort a given list of numbers, there are several sorting Algorithm as follow:
Type of Sorting Algorithm
Quick Sort.
Bubble Sort.
Merge Sort.
Insertion Sort.
Selection Sort.
Heap Sort.
Bucket Sort.

Here in this post we will write a function to take a given list and sort it then pass it back. We assume the user will enter a serial of numbers, that he want to sort, our function will sort it and print out the original numbers and the sorted one.

Quick Sort Steps of Quick Sorting Algorithm are:
1 – Save the first element of the list as pivot. We will call it as pv .
2 – Define Two variables i and j. We will call them as fc, lc fc will be 0 (first element position in the list) and lc will be the length of the list.(last element position in the list) .
3 – Increment fc until the number in the list in fc position is smaller or equal to pv (the first element).
4 – Decrement lc until the number in the list in lc position smaller than pv.

until list[j] < pivot then stop.
5 – If fc less than lc then we swap the two elements in the location of fc and lc. (SWAP list[fc] and list[lc]).

7 – Exchange the pivot element with list[j] element.

Coding First we will write a sort Menu for the project, we will have tree items to select from, Quick Sort Algorithm – Fast Run and Quick Sort Algorithm – Step By Step This will show sorting details.

``` # Main Menu

os.system('clear')

print('\n\n',' '*5,'******************************')
print(' '*5,' ***','  Sorting Algorithm ',' '*1,'***')
print(' '*5,' ***','     Quick Sort     ',' '*1,'***')
print(' '*5,' ***',' '*22,'***')
print(' '*5,' ******************************\n\n')

print(' '*7,'1. Quick Sort Algorithm - Fast Run.')
print(' '*7,'2. Quick Sort Algorithm - Step By Step.')
print(' '*7,'9. Exit.')

user_choice = input('\n   Select your choice.  > ')
return user_choice

```

And this is the main code body that will call the menu and check the user selection ..

``` # The Main application Body

while True:

if user_select == '1' :
user_list = create_list()

fpos = 0  # first position index
lpos = len(user_list)-1  # last position index

original_list = user_list
print('\n   The original List is: ',original_list)

user_sorted_list = quick_sort(user_list,fpos,lpos)

print('\n   DONE .. We Finish Sorting .. ')
print('   The Sorted List is: > ',user_sorted_list)
input('\n   ...Press any key to continue.  ')

if user_select == '2' :
user_list = create_list()

print('\n   We will show the Quick Sorting Step By Step... \n')
fpos = 0  # first position index
lpos = len(user_list)-1  # last position index
original_list = user_list

print('\n   The Original List is: ',original_list)
user_list = quick_sort_details(user_list,fpos,lpos)

print('\n   DONE .. We Finish Sorting .. ')
print('   The Sorted List is: > ',user_list)
input('\n   ...Press any key to continue.  ')

if user_select == '9' :
break
```

Also we will have a Function to take the List of Elements from the user, the user input will be as a string, we will convert it to an integer List and will return it back.. Here is the code ..

``` # Create the List

def create_list():
print('\n   Enter the List Elements separated by SPACE, when Finish just Press Enter.')
the_list = input('\n   Start Entering the Numbers in the List. >  ')

# Convert user input to List
the_list = the_list.split()

# Convert str list to int list
the_list = [int(each) for each in the_list]

return the_list
```

Now let’s write the Quick_sort function, then we will duplicaet it and add some print statements to show sorting steps. So first the code for Quick Sort Algorithm – Fast Run. Here is the code ..

 Screen shot of the Quick Sort Algorithm – Fast Run. Running this Function will return the sorted list and display it on the screen, I thought it will be nice if we show the sorting process Step by Step, so I copy the same Function with adding some print-statement in-between .. here is the code and the run-output..

End of Sorting Algorithm (1.Quick Sort) Follow me on Twitter..

## Python: Testing the SQL joines Commands

Learning : SQL Commands, DataBase, Python
Subject: Testing the SQL Join Commands

Introduction In this post we will apply several SQL Join Commands to test them, here are them:

 Left Join: All the Data in the Category Right Join: All the Data in the Products Inner Join: All the Data that in Both Tables. Left Join Only Data in Category Table and NOT in Product Table. Right Join:Only data in Product Table and NOT in Category Table. Full Outre:All the Records in both Tables Full Outre:All the data from the Category Table that are NOT linked to any Product, AND all the data in Product Table that has NO Category. First: let’s talk about the Tables,we will create two Tables (Category and Products) each will be very simple, the Category will have two fields [c_id, and cat_name],
the Products will have [p_id, pro_name, cat_id]. (cat_id is the foreign key that connicting the two tables). Some test data will be inserted in both Tables so we can demonstrate the SQL Commands. I create a Dictionary storing information/summary about the project named about_the_project the user can read it in run time.

Coding: We will do the fowlloing:
1. Set a Database for the Project.
2. Writing the codes to Create the Tables.
3. Writing the codes to insert some test Data in the Tables.
4. Creating a Menu for the Project.
5. Writing the Functions to Apply the SQL Join commmands.

Let’s import some lybraries, we will need this code:

import sqlite3, os

And here is the code to set the data base and create the connection.
# Create the data-base and name it as Share_S_System.
db_conn = sqlite3.connect (“sql_join_test.db”)

# set the connection.
c = db_conn.cursor()

First function is to create the Tables:

``` # Function to create the Tables.

def create_tables ():

# CREATE TABLE:
category_t = "CREATE TABLE if not exists category_t (c_id INTEGER PRIMARY KEY AUTOINCREMENT, cat_name text)"
c.execute(category_t)
db_conn.commit()

product_t = "CREATE TABLE if not exists product_t (p_id INTEGER PRIMARY KEY AUTOINCREMENT, p_name text, cat_id integer)"
c.execute(product_t)
db_conn.commit()

```

Now we will insert some Test data.

``` # Function to insert some Data into the Tables

def insert_sample_data():

#First we will call the Function to Crete the Table.
create_tables ()
print('\n   Category Table has been Created. ')
print('\n   Product Table has been Created. ')

# Insert into Category Table
c.execute ("INSERT INTO category_t (cat_name) VALUES(:cat_name )",{"cat_name":"Mobile Phone"})
c.execute ("INSERT INTO category_t (cat_name) VALUES(:cat_name )",{"cat_name":"Labtop"})
c.execute ("INSERT INTO category_t (cat_name) VALUES(:cat_name )",{"cat_name":"Ext. HD"})
c.execute ("INSERT INTO category_t (cat_name) VALUES(:cat_name )",{"cat_name":"CCTV Camera"})
db_conn.commit()

# Insert into Product Table.
c.execute ("INSERT INTO product_t (p_name, cat_id) VALUES(:p_name, :cat_id )",{"p_name":"Note 9","cat_id":"1"})
c.execute ("INSERT INTO product_t (p_name, cat_id) VALUES(:p_name, :cat_id )",{"p_name":"iPhone 12 pro","cat_id":"1"})
c.execute ("INSERT INTO product_t (p_name, cat_id) VALUES(:p_name, :cat_id )",{"p_name":"HP","cat_id":"2"})
c.execute ("INSERT INTO product_t (p_name, cat_id) VALUES(:p_name, :cat_id )",{"p_name":"Toshiba 1T HD","cat_id":"3"})
c.execute ("INSERT INTO product_t (p_name, cat_id) VALUES(:p_name, :cat_id )",{"p_name":"iMac","cat_id":None})
db_conn.commit()

print('\n   Sample Date Inserted in both tables.\n   Select 9 from the Main Menu to see the Data')

input('\n      ... Press any key to continue.  > ')
```

Now, let’s write the function for the Main Menu, it will return the user_choice.. here is the code..

``` # Main Menu Function.

os.system('clear')
print(' 2. All Categories. (Left Join: All in Category Only).')
print(' 4. Only Categories that linked to a Products. (Inner Join: Only if in Ta AND Tb).')
print(' 5. All Catigories that are NOT linked to a Product. (Left Join: Only in Category AND NOT in Product .')
print(' 6. All Products that has NO Category. (Right Join: Only in Product AND NOT in Category.')
print(' 7. All Categories and Products. (Full Outer Join in Both Table)' )
print(' 8. All Categories that are NOT linked to any Product, and All Products that has NO Categotry. (Full Outer Join NOT in Both Table)')
print(' 9. Show the Data')
print(' 11. Setting: Create the Tables and Insert Some Sample Data. Run Only One Time.')
print(' 99. Exit.')

user_choice = input("\n Select from the Menu: > ")
return user_choice
```

The coming part of the code is calling the functions and running the SQL commands based on the user choice. Here is the Main-code-body..

``` # The Main section of the Application..

while True :

if user_select == '1' :
show_data('cat')

if user_select == '2' :
show_data('prod')

if user_select == '3' :
os.system('clear')
print('\n   First: All the Data in Category and Product ')
show_data('both','inside')
print("\n==========[ Show Date: INNER JOIN ]==========\n")
print('   Inner Join: Only the Data that exist in Category AND Product).')
print('\n   The SQL Statment:\n    select category_t.c_id, product_t.p_name from category_t inner join product_t on category_t.c_id == product_t.cat_id\n\n ')
c.execute ("select category_t.c_id, category_t.cat_name, product_t.p_name from category_t inner join product_t on category_t.c_id == product_t.cat_id  ")
innerJ_list = c.fetchall()

print('   [OUTPUT]:\n       Categories Name      |',' '*2,'Products Name    ')
for innerJ_data in (innerJ_list):
print('       ',innerJ_data,'.'*(25 - len(str(innerJ_data))),innerJ_data)

print('\n   We can see that the INNER JOIN Command fetched the records of Products that has a Category.\n   iMac Not listed Because it has No Category Data.')
input('\n\n      ...Press any key to continue.  > ')

if user_select == '4' :
os.system('clear')
print('\n   List of All the Data in Category and Product ')
show_data('both','inside')
print("\n==========[ Show Date: LEFT JOIN, Only Data in Categoty Table ]==========\n")
print('   The SQL Statment:\n     select category_t.c_id, category_t.cat_name, product_t.p_name from category_t\n     left join product_t on category_t.c_id == product_t.cat_id\n     where product_t.cat_id is null\n')
c.execute ("select category_t.c_id, category_t.cat_name, product_t.p_name from category_t left join product_t on category_t.c_id == product_t.cat_id where product_t.cat_id is null")
leftJ_list = c.fetchall()
print('   [OUTPUT]:\n       Categories Name      |',' '*2,'Products Name    ')
for leftJ_data in (leftJ_list):
print('         ',leftJ_data,'.'*(25 - len(str(leftJ_data))),leftJ_data)

print('\n   We can see that the LEFT JOIN Command fetched all Categories that are not used/linked to/with any Product.\n   CCTV Camera is Not linked. So We can Say: We Do Not have any CCTV Camera Products.')
input('\n\n      ...Press any key to continue.  > ')

if user_select == '5' :
....
# Just to save the time, i will not post all the code here, you can see all the code and download
```

Here are some screen shot of the output ..

 The Main Menu Output Screen for Option 3: Only Categories that linked to a Products. (Inner Join: Only if Data in Category AND Product)
